MIDAM H/WLx7002xx
Free programmable room controller based on i.MX RT processor (FreeRTOS) and capacitive touch screen. It contains temperature, relative humidity and light intensity sensors. As an option it can feature CO2 sensor, various communication interfaces (Ethernet, RS485, KFP wireless) as well as multiple inputs/outputs.
- průmyslové krytí IP65
- velký výběr velikostí
- snadná konektivita
- velký výběr vlastností
- průmyslové krytí IP65
- snadná konektivita
vlhkost
wi-fi
teplota
test Funkce
The free programmable room controller H/WLx7002xx contains i.MX RT processor type with FreeRTOS operating system. It is based
on a high performance process platform for user application/ graphic development. The system is open and it is possible to
create customised user interfaces, control programs, data collection applications, or to manage other processes. The controller has its
own real-time clock, backed up with internal battery. As a default the H/WLx7002xx has no user application available. The application
is created and uploaded in the integrated development environment (IDE) provided by the device manufacturer. The H/WLx7002xx
is delivered with temperature and relative humidity sensor as a standard or equipped with CO2 sensor as an optionand it features a
built-in light intensity sensor too. The optional equipment is specified by a special device code (-xx). The combination options are listed
at the end of the document and correspond to the Midam price list.
KFP Wireless communication option
Wireless communication is based on an unlicensed 868 MHz band and uses higher radio frequency transmitter power up to +20 dBm. WLx7002xx embeds AES 128-bit, the most secure encryption standard for wireless connections to date and is compatible with the entire range of Midam KFP wireless system devices.
SCADA system integration
Direct integration into various SCADA systems through wired
Modbus RT, OPC UA, Modbus TCP or BACnet/IP (RJ45) protocols
is possible
